Page 63 - Catalogue solaire NOVEA
P. 63

COMBINAISONS SOLAIRES

               SOLAR COMBINATIONS





               COMMENT CHOISIR SA COMBINAISON ?

               HOW TO SELECT THE APPROPRIATE COMBINATION?


                    1-DÉFINITION DU PROJET                                     1-PROJECT DEFINITION
                    - Localisation géographique                                - Geographical location
                    - Défi nition du type de lieu à éclairer (route,           - Defi nition of the type of location to illuminate (road,
                    chemin, place, jardin...)                                  lane, square, garden, etc.)

                    2-CHOIX DE L’ÉCLAIRAGE                                     2-CHOICE OF LIGHTING
                    Luminaire à LED de la gamme RAGNI :                        RAGNI range LED luminaire:
                    - Puissance et intensité lumineuse                         - Power and luminous intensity
                    - Design                                                   - Design
                    - Distribution photométrique                               - Photometric distribution

                    3-DIMENSIONNEMENT DE L’ENSEMBLE                            3-FIXTURE SIZING
                    Défi nition des composants solaires :                      Defi nition of solar components:
                    - Type, puissance et taille du panneau solaire             - Solar panel type, power and size
                    - Type et nombre de batterie(s)                            - Type and number of battery(ies)
                    - Type et dimensions du support/mât                        - Support/pole type and dimensions

                    4-CHOIX DE LA CONFIGURATION                                4-CHOICE OF CONFIGURATION
     62             Emplacement des appareillages :                            Equipment location:





















                                      APPAREILLAGE EN PIED DE POTEAU EQUIPMENT IN POLE BASE  APPAREILLAGE DANS LA BORNE DU MÂT EQUIPMENT IN POLE POST  APPAREILLAGE DANS UN CAISSON EN TOP DE MÂT EQUIPMENT IN POLE TOP BOX  APPAREILLAGE DANS UN CAISSON DÉPORTÉ  EQUIPMENT IN REMOTE BOX
